Y-bearings take-up units TUWK 30 LTHR

Bearing number : TUWK 30 LTHR

Size (mm) : 30x34x12

Brand : SKF

Bore Diameter (mm) : 30

Outer Diameter (mm) : 34

Width (mm) : 12

Bearing dimensions and specification in SKF catalogue:

d - 30 mm

A - 34 mm

A1 - 12 mm

A2 - 30 mm

A5 - 26.5 mm

B - 38.1 mm

H - 102.5 mm

H1 - 89 mm

H2 - 40 mm

L - 125 mm

L1 - 76 mm

L3 - 63.5 mm

G - M16

G1 - 21 mm

s1 - 22.2 mm

Basic dynamic load rating - C - 16.3 kN

Basic static load rating - C0 - 11.2 kN

Fatigue load limit - Pu - 0.475 kN

Limiting speed with shaft tolerance h6 - 3800 r/min

Mass bearing unit - 0.62 kg

Grub (set) screw - G2 - M6x0.75

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 4 N·m

Housing - TUWK 506 L

Bearing - YAR 206-2RFGR/HV

End cover - ECL 206
