Y-bearings take-up units TUWK 20 LTHR

Bearing number : TUWK 20 LTHR

Size (mm) : 20x27.5x12

Brand : SKF

Bore Diameter (mm) : 20

Outer Diameter (mm) : 27,5

Width (mm) : 12

Bearing dimensions and specification in SKF catalogue:

d - 20 mm

A - 27.5 mm

A1 - 12 mm

A2 - 24.5 mm

A5 - 20.3 mm

B - 31 mm

H - 89 mm

H1 - 76 mm

H2 - 36 mm

L - 99 mm

L1 - 64 mm

L3 - 46 mm

G - M16

G1 - 21 mm

s1 - 18.3 mm

Basic dynamic load rating - C - 10.8 kN

Basic static load rating - C0 - 6.6 kN

Fatigue load limit - Pu - 0.28 kN

Limiting speed with shaft tolerance h6 - 5000 r/min

Mass bearing unit - 0.34 kg

Grub (set) screw - G2 - M6x0.75

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 4 N·m

Housing - TUWK 504 L

Bearing - YAR 204-2RFGR/HV

End cover - ECL 204
