Bearing TUWK 1.1/4 LTA Bearing TUWK 1.1/4 LTA

Y-bearings take-up units TUWK 1.1/4 LTA

Bearing number : TUWK 1.1/4 LTA

Size (mm) : 31.75x34x12

Brand : SKF

Bore Diameter (mm) : 31,75

Outer Diameter (mm) : 34

Width (mm) : 12

Bearing dimensions and specification in SKF catalogue:


d - 31.75 mm

A - 34 mm

A1 - 12 mm

A2 - 30 mm

A5 - 28.2 mm

B - 42.9 mm

H - 102.5 mm

H1 - 89 mm

H2 - 40 mm

L - 125 mm

L1 - 76 mm

L3 - 63.5 mm

G - M16

G1 - 21 mm

s1 - 25.4 mm

Basic dynamic load rating - C - 25.5 kN

Basic static load rating - C0 - 15.3 kN

Fatigue load limit - Pu - 0.655 kN

Limiting speed with shaft tolerance h6 - 3200 r/min

Mass bearing unit - 0.77 kg

Grub (set) screw - G2 - 5/16-24 UNF

Hexagonal key size for grub screw - H - 3.969 mm

Recommended tightening torque for grub screw - 6.5 N·m

Housing - TUWK 507 L

Bearing - YAR 207-104-2RF/VE495

End cover - ECL 207
