Concentra bearing units SYR 2 3/4 N

Bearing number : SYR 2 3/4 N

Size (mm) : 68,262x69,85x65,484

Brand : SKF

Bore Diameter (mm) : 68,262

Outer Diameter (mm) : 69,85

Width (mm) : 65,484

Bearing dimensions and specification in SKF catalogue:

da - 69.85 mm

A - 68.262 mm

B - 65.484 mm

H - 165.894 mm

H1 - 82.55 mm

H2 - 57.15 mm

L - 265.112 mm

J - max. - 223.838 mm

J - min. - 198.438 mm

s - 32.941 mm

S - 0.794 mm

Basic dynamic load rating - C - 212 kN

Limiting speed - 2800 r/min

Mass bearing unit - 9.98 kg
