Concentra bearing units SYR 2 3/16 N

Bearing number : SYR 2 3/16 N

Size (mm) : 55.562x60.325x59.531

Brand : SKF

Bore Diameter (mm) : 55,562

Outer Diameter (mm) : 60,325

Width (mm) : 59,531

Bearing dimensions and specification in SKF catalogue:

da - 55.562 mm

A - 60.325 mm

B - 59.531 mm

H - 129.778 mm

H1 - 63.5 mm

H2 - 41.275 mm

L - 225.425 mm

J - max. - 187.325 mm

J - min. - 163.512 mm

s - 29.766 mm

S - 0.794 mm

Basic dynamic load rating - C - 125 kN

Limiting speed - 3700 r/min

Mass bearing unit - 5.44 kg
