Radial spherical plain bearings SILA40ES-2RS

Bearing number : SILA40ES-2RS

Brand : SKF

Bore Diameter (mm) : 40

Bearing dimensions and specification in SKF catalogue:

d - 40 mm

d2 - 94 mm

d4 - 58 mm

dk - 53 mm

h1 - 142 mm

l3 min. - 65 mm

l4 max. - 191 mm

l5 - 25 mm

l7 min. - 46 mm

r1 min. - 0,6 mm

B - 28 mm

C1 max - 24 mm

w - 50 Tolerance h14

Thread (G) - M39x3 Tolerance 6H

Angle - 6 °

Weight - 2,2 Kg

Basic dynamic load rating (C) - 100 kN

Basic static load rating (C0) - 166 kN
