Deep groove ball bearings, single row, with filling slots 215-ZNR

Bearing number : 215-ZNR

Size (mm) : 75x130x25

Brand : SKF

Bore Diameter (mm) : 75

Outer Diameter (mm) : 130

Width (mm) : 25

Bearing dimensions and specification in SKF catalogue:

d - 75 mm

D - 130 mm

B - 25 mm

d1 - - 92.05 mm

D2 - - 116.5 mm

D3 - 125.22 mm

D4 - 139.7 mm

b - 3.1 mm

C - 4.06 mm

f - 2.82 mm

r0 - 0.6 mm

r1,2 - min. - 1.5 mm

da - min. - 84 mm

da - max. - 92 mm

Da - max. - 121 mm

Db - min. - 141 mm

ba - min. - 3.5 mm

Ca - max. - 6.88 mm

ra - max. - 1.5 mm

Basic dynamic load rating - C - 72.1 kN

Basic static load rating - C0 - 72 kN

Fatigue load limit - Pu - 3 kN

Reference speed - 9000 r/min

Limiting speed - 5300 r/min

Calculation factor minimum radial load - kr - 0.04

Mass bearing - 1.25 kg

Snap ring - SP 130
