Deep groove ball bearings, single row, with filling slots 208-2ZNR

Bearing number : 208-2ZNR

Size (mm) : 40x80x18

Brand : SKF

Bore Diameter (mm) : 40

Outer Diameter (mm) : 80

Width (mm) : 18

Bearing dimensions and specification in SKF catalogue:

d - 40 mm

D - 80 mm

B - 18 mm

d1 - - 52.6 mm

D2 - - 69.8 mm

D3 - 76.81 mm

D4 - 86.6 mm

b - 1.9 mm

C - 3.28 mm

f - 1.7 mm

r0 - 0.6 mm

r1,2 - min. - 1.1 mm

da - min. - 47 mm

da - max. - 52.5 mm

Da - max. - 73 mm

Db - min. - 88 mm

ba - min. - 2.2 mm

Ca - max. - 4.98 mm

ra - max. - 1 mm

Basic dynamic load rating - C - 33.6 kN

Basic static load rating - C0 - 27 kN

Fatigue load limit - Pu - 1.2 kN

Reference speed - 15000 r/min

Limiting speed - 7600 r/min

Calculation factor minimum radial load - kr - 0.04

Mass bearing - 0.39 kg

Snap ring - SP 80
