Y-bearings take-up units TUWK 1.1/2 LTA

Bearing number : TUWK 1.1/2 LTA

Size (mm) : 34x38,1x16

Brand : SKF

Bore Diameter (mm) : 34

Outer Diameter (mm) : 38,1

Width (mm) : 16

Bearing dimensions and specification in SKF catalogue:

d - 38.1 mm

A - 34 mm

A1 - 16 mm

A2 - 32 mm

A5 - 33.6 mm

B - 49.2 mm

H - 114 mm

H1 - 102 mm

H2 - 40 mm

L - 140 mm

L1 - 85 mm

L3 - 80 mm

G - M16

G1 - 21 mm

s1 - 30.2 mm

Basic dynamic load rating - C - 30.7 kN

Basic static load rating - C0 - 19 kN

Fatigue load limit - Pu - 0.8 kN

Limiting speed with shaft tolerance h6 - 2800 r/min

Mass bearing unit - 0.99 kg

Grub (set) screw - G2 - 5/16-24 UNF

Hexagonal key size for grub screw - H - 3.969 mm

Recommended tightening torque for grub screw - 6.5 N·m

Housing - TUWK 508 L

Bearing - YAR 208-108-2RF/VE495

End cover - ECL 208
