Concentra bearing units SYNT 35 FW

Bearing number : SYNT 35 FW

Size (mm) : 35x60x65

Brand : SKF

Bore Diameter (mm) : 35

Outer Diameter (mm) : 60

Width (mm) : 65

Bearing dimensions and specification in SKF catalogue:

da - 35 mm

A - 60 mm

B - 65 mm

H - 111 mm

H1 - 60 mm

H2 - 25 mm

J - 170 mm

L - 205 mm

H - 20 mm

N1 - 15 mm

J6 - 185 mm

J7 - 21 mm

N4 - max. - 6 mm

A3 - 50 mm

A5 - 22 mm

ba - min. - 34 mm

ba - max. - 43 mm

Basic dynamic load rating - C - 86.5 kN

Basic static load rating - C0 - 85 kN

Fatigue load limit - Pu - 9.3 kN

Limiting speed - 4100 r/min

Calculation factor - e - 0.31

Calculation factor - Y1 - 2.2

Calculation factor - Y2 - 3.3

Diameter - dm - 53.5 mm

Basic Designation bearing - 22207 E

Pa - 15 kN

P0° - 150 kN

P55° - 250 kN

P90° - 150 kN

P120° - 95 kN

P150° - 85 kN

P180° - 105 kN

Mass bearing unit - 3.8 kg

Diameter - G - 12 mm
